Thermodynamic principle is the essential in steam engineering, it involves with study of phase changes between water and steam. Steam engineering products refer to various equipment, components, and systems used in the generation, distribution, and utilization of steam. These products are essential in industries such as power generation, manufacturing, chemical processing, and heating

Steam distribution and control is needed to deliver steam efficiently where needed, the steam distribution covers piping system, valves, pressure regulators and conditioning

Pressure Regulating Valve

Special control valve for high temperature and pressure application. Heavy industrial application control valve for power generation service, valve can operate up to 600 Deg C with pressure 100 Bar.

Pressure Regulating Valve is a type of valve used to regulate pressure in a process. In the power generation industry, pressure regulating valves are widely used in regulating the flow of fluids both steam and water such as in extraction systems in turbines, feed water systems in boilers. PRV maintains pressure according to the set point on the downsteam valve

Function : Control, shut-off, Conditioning

Standard : EN, ANSI

Pressure Rating : PN 16-400/ 150-2500

Temp : up to 600 Deg C

Material : WC9 A217, WCB A216, A351CF8M

Connection : Flanged, Weld

Actuators : Pneumatic, Motorized

Desuperheater

Desuperheaters are usually installed after the boiler to bring the steam to the desired temperature or upstream of the turbine in the Power generation system. In the process industry, desuperheaters are used as part of a system to reduce the temperature and steam pressure of the boiler to an economical operating level.

The main function of the desuperheater water heater is to minimize the temperature of superheated gas and other steam. This temperature reduction is achieved by a steam process that comes into direct contact with liquids such as water.

Steam Trap

Model : Thermodynamic, Ball Float

Standard : ANSI, EN

Rating : up to #300, PN 40

Material : SA182F321, A 743, SA 82,SA 276 Gr 420, SA 105

Operating Pres : up to 32 Bar

DP Max : 32 Bar

Connection : flange, welded, socket

Thermocompression

Thermocompression is a static device for raising low-pressure steam into medium-pressure steam by mixing using high-pressure steam. The way it works is to increase the compression of high-pressure steam and convert it into kinetic energy which creates vacuum power loe low-pressure steam which is then mixed and expanded back into pressure

Motive Steam : 0.6 -2 Mpa G

Operation Temp : 220 Deg C

Suction capacity : 100 -700 kg/hr

Source : saturated steam

Application : reuse of flash steam, utilize venting. Dryers, condensate receiver, Exhaust

line, Steam Refrigeration

Material : Carbon Steel
